T4010F Fluoride Ion Monitor
-
Instrument Features:
● Color LCD display
● Intelligent menu operation
● Multiple automatic calibration functions
● Differential signal measurement mode for stable and reliable performance
● Manual/automatic temperature compensation
● Dual relay control switches
● Upper limit, lower limit, and hysteresis control
● Multiple outputs: 4-20mA & RS485
● Simultaneous display of ion concentration, temperature, current, etc.
● Password protection to prevent unauthorized operation
Technical Specifications:
(1) Measurement Range (based on electrode capacity):
Concentration: 0.02–2000 mg/L;
(Solution pH: 5–7 pH)
Temperature: -10–150.0°C;
(2) Resolution:
Concentration: 0.01/0.1/1 mg/L;
Temperature: 0.1°C;
(3) Basic Error:
Concentration: ±5-10% (based on electrode range);
Temperature: ±0.3°C;
(4) Dual Current Output:
0/4–20mA (load resistance <750Ω);
20–4mA (load resistance <750Ω);
(5) Communication Output: RS485 MODBUS RTU;
(6) Dual Relay Control Contacts:
3A 250VAC, 3A 30VDC;
(7) Power Supply (Optional):
85–265 VAC ±10%, 50±1 Hz, Power ≤3 W;
9–36 VDC, Power: ≤3 W;
(8) Dimensions: 98 × 98 × 130 mm;
(9) Mounting: Panel-mounted, Wall-mounted;
Panel Cutout Dimensions: 92.5×92.5mm;
(10) Protection Rating: IP65;
(11) Instrument Weight: 0.6kg;
(12) Instrument Operating Environment:
Ambient Temperature: -10～60℃;
Relative Humidity: ≤90%;
No strong magnetic field interference except Earth's magnetic field.
